| Machine Features | Description |
| 1300*2500mm effective working area | 8-10mm Steel gantry, big and thick square tube, heavy-duty structure |
| Bigger welded steel tube machine body | Thicker steel tube frame with 4legs(also have 4 adjust screw), more solid and stable for the machine |
| 5.5KW water cooling spindle 0-24000 rpm Can update spindle power accordingly | With lower noise, easy maintenance, use industry standard ER collects, From 0-24000rpm/min. |
| DSPA11 control system | Famous Brand control system ,computer control panel with USB |
| Leadshine big driver | 4sets in total, double motors for Y axis, Each one for X and Z axis |
| Taiwan linear guide way for X,Y,Z axis | Famous brand, can improve high precision, smooth transmission, fast speed, low noise, and it has 10 times longer life than normal |
| Helical rack gears for X,Y axis | 1.25M, big loading capacity, very powerful for machine, long lifetime |
| Taiwan TBI ball screw for Z axis | Accurate precision, smooth transmission. |
| oil lubrication system | Help lubricate the rail way, maintaining machine good performance. |
| Soft limit switch | Help to protect machine axis. |
| Working voltage | 380V,3phase,50HZ |
| software | Professional software artcam software |
| Standard Accessories equipped : | Tool Box 1set One set of engraving cutters ER20 2 pcs collet 3.175mm 1pc ,6mm 1pc Fixture :6pcs 6.Spanner 2pcs Adjustment screw 6pcs |
